Description
Overview:
The Shield Anchor - Loose Bolt, M16 x 60 (Hole Size: 24 mm), is a heavy‐duty mechanical fixing for solid masonry such as concrete, brick and natural stone. Made from steel with a corrosion‐resistant zinc‐plated finish, it uses a four‐piece segmented shield and a captive expansion cone to lock securely into the drilled hole. The loose bolt design lets you position the fixture before tightening, making it a practical choice for installing machinery base plates, brackets and structural fittings. Suitable for construction and maintenance work on site or in workshops, it provides strong, reliable anchoring for tools and machines that need stable, long‐lasting support, such as compressors or generators. Supplied individually for convenient quantity control. Manufacturer Part Number (MPN): 903 2215.
Key Features:
- M16 x 60 overall size with 24 mm drill hole diameter; sold individually for precise ordering
- Four‐piece shield spreads the load and grips the substrate for a secure hold
- Captive expansion cone delivers positive setting and helps prevent spin in the hole
- Zinc‐plated steel construction for durability and corrosion resistance in indoor and sheltered outdoor conditions
- Suitable for solid masonry: cast concrete, brickwork, dense block and natural stone
- Loose‐bolt format allows easy alignment of base plates, brackets and fixtures before final tightening
- Installs with a standard 24 mm masonry drill and hand tools; straightforward, clean fitting process
- Reliable performance for heavy loads when installed to guidance and into sound substrates
- Versatile choice for construction, repair and upgrade works on buildings, plant rooms and workshops
- MPN 903 2215 for easy identification; part of a range typically covering M6 x 10 up to M16 x 60
Typical Applications:
Fixing machinery and equipment base plates, setting structural and angle brackets, securing handrails and safety barriers, mounting racking, shelving, pipe clamps and cable tray, attaching gates and posts to concrete, and reinforcing existing installations in solid masonry where a dependable, long‐term anchor is required.
Also known as:
Shield anchor (loose bolt type), rawlbolt style fixing, heavy‐duty masonry fixing, metal wall anchor, expansion shield anchor, four‐segment shield fixing, construction anchor for solid substrates.
Product Specifications
| L&S Part No. | 903 2215 |
|---|---|
| Unit of Sale | Each |
| Size | M16 x 60 - Hole Size 24mm |
| Key Features | - M16 x 60 size with 24 mm drill hole - Four-piece shield ensures secure load distribution - Captive expansion cone prevents spin in the hole - Zinc-plated steel for corrosion resistance - Suitable for concrete, brick, and natural stone |
