Description
Overview:
This Shield Anchor with loose bolt (size M12 x 60) is a traditional expansion fixing designed for solid masonry. It uses a 4‐piece segmented body and a captive expansion cone to grip the sides of the drilled hole as the bolt is tightened, creating a secure and reliable hold. Manufactured from robust steel with a corrosion‐resistant plated finish, it is suitable for use in concrete, solid brick and natural stone. The loose bolt format allows the fixture to be removed or adjusted without disturbing the anchor body, which is useful for maintenance and repositioning. Requires a 20 mm hole diameter. Supplied individually, it suits one‐off repairs as well as site work. Part of a range typically available from M6 x 10 to M16 x 60; this listing is for M12 x 60.
Key Features:
- M12 x 60 loose bolt shield anchor for medium to heavy‐duty fixings
- 20 mm hole size for correct installation and holding performance
- Traditional 4‐piece segmented body spreads load in solid masonry
- Captive expansion cone for consistent, controlled expansion during tightening
- Loose bolt allows fixture removal/re‐fit without withdrawing the shield
- Steel construction with a protective plated finish for corrosion resistance
- Reliable holding in concrete, solid brick and stone (not for hollow substrates)
- Suited to baseplates, brackets, guards and frames on workshop and site equipment
- Straightforward installation with standard masonry drill and spanner
- Sold individually to reduce waste and match job quantities
Typical Applications:
Fixing machinery baseplates, tool stands, compressors, generators, racking, shelving, brackets, balustrades, handrails, gate posts, pipe clips and heavy‐duty hardware to concrete, solid brick or stone. Common on construction sites, workshops, farm buildings, garages and garden structures where a secure, dependable anchor is needed and fixtures may need periodic removal or adjustment.
Also known as:
Loose bolt anchor, heavy‐duty masonry anchor, expansion shield, anchor bolt, shield fixing, four‐segment anchor, Rawl type anchor, masonry fixing bolt, mechanical anchor, concrete anchor.
Product Specifications
| L&S Part No. | 903 2212 |
|---|---|
| Unit of Sale | Each |
| Size | M12 x 60 - Hole Size 20mm |
| Key Features | - M12 x 60 size for medium to heavy-duty fixings - Requires 20 mm hole diameter for installation - 4-piece segmented body for load distribution - Captive expansion cone ensures controlled expansion - Steel with corrosion-resistant plated finish |
