Description
Overview:
The Shield Anchor - Loose Bolt (M12 x 10, 20 mm hole size) is a heavy-duty mechanical fixing for solid masonry such as concrete, solid brick, and natural stone. Made from zinc-plated steel for general corrosion resistance and long service life, it uses a four-piece segmented shield and a captive expansion cone to lock securely in the substrate when tightened. The loose bolt design allows the fixture to be positioned before final tightening, making it suitable for base plates, brackets, machinery feet, and structural fixings. Common in construction, workshop, and landscaping settings, it offers a dependable hold where high shear and tensile loads are expected. Manufacturer Part Number: 903 2210. Sold individually for flexible ordering and maintenance.
Key Features:
- M12 x 10 size with 20 mm drill hole requirement for reliable expansion in solid masonry
- Four-piece segmented shield delivers strong, uniform expansion and excellent grip
- Captive expansion cone prevents slip, aiding consistent installation and load performance
- Zinc-plated steel construction for durability and general corrosion resistance
- Loose bolt style helps align fixtures before final tightening for easier fitting
- Suitable for concrete, solid brick, and natural stone (not recommended for hollow block)
- Hex-head tightening for straightforward installation with standard hand tools
- Robust choice for high-load applications in construction and workshop environments
- Sold individually to match exact project quantities and reduce waste
- Available range covers M6 x 10 to M16 x 60 for different fixture and load requirements
Typical Applications:
Securing machinery base plates, racking, shelving uprights, brackets, angle plates, pallet stops, handrails, gate hardware, post shoes, pipe clamps, compressor feet, bench legs, and safety barriers into concrete or solid brick. Suitable for installing garden machinery mounts, anchors for pergola/base fixings, and heavy fixtures in garages and workshops where a reliable, permanent fixing is required.
Also known as:
Shield fixing, sleeve anchor (loose bolt type), masonry shield, heavy-duty anchor, expansion fixing, concrete bolt anchor, through-fixing anchor, mechanical anchor, wedge-style shield, fixing bolt for masonry.
Product Specifications
| L&S Part No. | 903 2210 |
|---|---|
| Unit of Sale | Each |
| Size | M12 x 10 - Hole Size 20mm |
| Machine Type | Handheld Construction Tools |
| Key Features | - M12 x 10 size with 20 mm drill hole requirement - Four-piece segmented shield for strong, uniform expansion - Captive expansion cone ensures consistent installation - Zinc-plated steel for corrosion resistance - Suitable for concrete, solid brick, and natural stone |
