How to Convert an Electric Motor to a Loncin G120 / Honda GX120 Petrol Engine on a Belle Minimix 150
In this video, we show you how to convert a Belle Minimix 150 to a Loncin G120 / Honda GX120 from an electric motor.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today, we're going to Convert a Belle Minimix 150 from an electric motor to a loncin G120 (GX120 equivalent) petrol engine. First remove the drum by turning it anticlockwise. Now you will need to remove the 5 screws on the belt guard using a crosshead screwdriver. Next remove the spring washer from the shaft with a flathead screwdriver. Then remove the existing pulley from the shaft, the easiest option is to break the pulley off. Now using a 14mm hex socket spanner unscrew the 4 bolts located on the front of the machine to release the electric motor assembly. Next tap the new pulley onto the shaft followed by the new spring washer, use a socket and a hammer to push the washer on straight. Bolt the engine to the deck using M8 Nuts and Bolts with a 14mm hex socket spanner and 14mm spanner. Now attach the mounting deck with the engine mounted, secure with an M12 nut and bolt using a 19mm hex socket spanner and a 19mm spanner. Now replace the drive belt. screw the cover back into position using a crosshead screwdriver to secure the 2 screws. Now you can reattach the drum. That's how to Convert the Complete Electric Motor Housing to a GX120 Type Petrol Engine on a Belle Minimix 150 All the parts & tools needed for this task are listed in the description below.
Parts
Parts and tools included in the Minimix 150 cement mixer how-to video.
- Loncin G120 Engine Conversion - 101 602
- Loncin G120 - 700 710
- Honda GX120 - GX120 QX
- Gearbox Pulley Kit - 900/30000
- Belle Minimix 150 Drive Belt 900/99915
- 600 Series Screwdriver Set 6 Piece SL/PH/PZ by Bahco - STA086775
- Hexagon Socket 3/8in Drive 19mm by Faithfull - FAISOC3819
- Combination Ring/Open Ended Spanner 19mm - 902 0014
- 208 Copper / Hide Hammer Size A (25mm / 1") 400g - 902 2160
