How to Change the Handle Vibration Mounts on a PCLX 320 Plate Compactor
In this video, we show you how to change the handle vibration mounts on a Belle PCLX 320 Plate Compactor.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Today we're going to change the vibration mounts (near the handle) on a Belle PCLX 320 Plate Compactor. Firstly, loosen the 4 bolts and washers on the outside of the brackets using a 13mm socket and ratchet. Then, unfasten the 2 larger bolts using a 24mm socket. You can use an adjustable wrenc h to hold the brackets in place when removing. You can now remove the handle and brackets. Additionally slide out the bar strut. To disconnect the mounts, use a 13mm socket. Now screw the new mounts back into position and secure with the nuts. Place the bar strut back. Return the brackets and fasten with the bolts and washers. Now place the handle back, and fix with the 2 bolts.
Parts
Parts and tools included in the Belle PCLX 320 how-to video.
