How to Change the Handle & Brackets on a Belle PCLX 320 Plate Compactor
How to Change the Handle & Brackets on a Belle PCLX 320 Forward Plate Compactor.
Health & Safety Warning - Please ensure that you have safely prepared the machine and workspace. If you are unsure about any aspect of the task please seek professional advice.
Transcript
Firstly, loosen the 4 bolts and washers on the outside of the brackets using a 13mm socket and ratchet. Then, unfasten the 2 larger bolts using a 24mm socket. You can use an adjustable wrench to hold the brackets in place when removing. Now, remove the 4 bolts and washers using a 13mm socket. You can now disconnect the handle and brackets. Remove the brackets from the handle and secure with the washers and bolts. Put the handle back into position. Secure the handle with the bolts until tight. You may need to use the adjustable wrench to help hold the brackets and bar strut when securing the bolts.
Parts
Parts and tools included in the Belle PCLX 320 how-to video.
- Bahco S240 Socket Set of 24 Metric 1/2in Drive - 902 0092
